LEVITON 2815 Receptacle locking flanged 4P 5W 120/208V 30A white
lev2815
LEVITON 2815 Receptacle locking flanged 4P 5W 120/208V 30A white
Price
$178.54
/ EA
Inventory
Available for backorder
Manufacturer:LEVITON
Manufacturer #:2815
Description
Leviton's industry leading locking devices, such as our black white line of industrial grade plugs and connectors and our V-0-Max line of industrial grade flush receptacles, offer superior performance, long lasting reliability and other features that are backed by a lifetime warranty.
Specifications
| Brand Name | Leviton | Sub Brand | LOCKING DEVICES |
| Item Name | Flanged Inlet Locking Receptacle | Type | Locking Flanged Inlet |
| Number of Wires | 5 | Number of Poles | 4 |
| Voltage Rating | 120/208 V | Amperage Rating | 30 A |
| Conductor Size | 16-8 AWG | NEMA Configuration | WD-1, WD-6 |
| Color/Finish | White | Phase | 3 |
| Terminal Connection | Back Wired | Temperature Rating | -40 °C to 60 °C |
| Contact Material | Solid Brass | NEMA Rating | L21-30P |
| Dielectric Strength | 2000 V | Material | Nylon |
| Grounding | Grounding | Mounting Type | Flange |
| Dimensions | 33 in dia | Environmental Conditions | Flammability (Rated V-2 Per UL94) |
| Standards | ANSI C-73, CSA C22.2 No. 42 File Number LR-406, NEMA WD-1, WD-6, NOM 057 Certified, UL 498, UL File Number E13393, Federal Specification WC-596 | Application | For Commercial |
| UPC | 078477806562 |
Packages
| 1 - Unit | 10 - Crate | 900 - Pallet |
